Name: Smart embedded camera
Brand: GUANGZHOU OSTEC ELECTRONIC TECHNOLOGY CO.,LTD
Availability: InStock
Rating: 5 (1 reviews)

The smart embedded camera is designed for binocular microscopes. Equipped with a built-in reducing lens, user can get large field of view. Thanks to the dedicated 50:50 split-light module, the camera can help users to observe images simultaneously through eyepieces and camera without switching.

* Compatibility * Easy connection
* Large FOV * Highly Integrated

Robust and flexible microscope compatibility with Nikon Ei and Si. Designed as per the optical characteristics of Nikon brand and the size of the dovetail interface.
Different types of interfaces such as 5G WiFi, HDMI are available for option. Plug and play. Don't even need a computer when choosing an all-in-one type camera.
The built-in reduction lens and its magnification is designed according to the size of the camera sensor in order to get the largest field of view.
Built-in focusing mechanism, built-in reduction lens, built-in dichroic prism, built-in operating system, complex optical and mechanical modules are all integrated into a compact housing.

Work seamlessly with a wide range of computing and mobile devices based on Windows, iOS, or Android.

Come with imaging APP, automatically display live images after power on.

Embedded 50%/50% light splitting design without damaging the original optical system and Built-in high power reduction lens for large field of view.

Precise and simple focus of screw rod to realize eyepiece-to-monitor synchronization.

32GB built-in RAM, support U-disk storage for picture and video.

USB ports for wireless keyboard and mouse, easy to input and operate the system.

Mobile devices access the system by scanning the exclusive QR code.

Connect to PC through Wi-Fi, and 4K HDMI output to display, TV and projector

* High performance CMOS sensor
* High Speed 5G Wi-Fi 11acTechnology
* 30FPS at 4K output
* Support third-party Android apps

The camera is equiipped with Sony CMOS. High sensitivity, low dark current and no smear are achieved through the adoption of R,G and B primary color mosaic filters.
The 5th generation Wi-Fi (IEEE 802.11ac) technology ensures the camera can stably run at 30 fps at 4K preview, which is at least 3 times of IEEE 802.11n.

The industrial-grade non-touch screen can effectively prevent the shaking of the microscope caused by finger clicks, and is more conducive to stable image observation.The standard accessories include a mouse and keyboard, which can operate the all-in-one smart display camera like a computer, allowing users to insert a U-disk to install third-party Android apps, such as Office apk, pathology analysis APP, education APP etc.

KoPa Capture for Windows systems

Image & Measuring Software
Standard microscopy imaging and measurement software included with the camera

KoPa WiFi Lab AO

Built-in Imaging App
When start the camera, you will directly enter KoPa WiFi Lab AO and automatically live-stream images. This APP is permanently retained and will not be deleted by mistake.

KoPa WiFi Lab

App for mobile phones and tablets( iOS and android systems)

Camera parameters

Physical pixel	12.0MP	8.0MP
Camera model	HW1200(N)	HW800(N)
Applicable microscope	Nikon Ei / Si series Binocular	Nikon Ei / Si series Binocular
Windows PC Software	KoPa Capture	KoPa Capture
Embedded APP	KoPa WiFi Lab AO	KoPa WiFi Lab AO
APP for iOS / android mobile phone/tablet	KoPa WiFi Lab	KoPa WiFi Lab
5G WiFi Output	Available	Available
HDMI Output	Available	Available
USB Output	N / A	N / A
Sensor model	Sony IMX412 CMOS	Sony IMX334 CMOS
Exposure mode	Roller shutter exposure	Roller shutter exposure
Highest resolution	4000x 3000 (12.000.000)	3840×2160 (8,294,400)
Sensor size	1/2.3”	1/1.8”
Pixel size	1.55μm×1.55μm	2.0μm×2.0μm
Spectral response	380-650nm	380-650nm
White balance	Real-time auto manual adjustment	Real-time auto manual adjustment
Preview resolution	4000×3000,3840×2160, 2592×1944, 1920×1080	3840×2160, 2592×1944 1920×1080
Exposure	Automatic and manual	Automatic and manual
Record format	Snapshot Format：JPG Resolution: 4000×3000,3840×2160 , 2592×1944,1920×1080 Record Format：MP4 file Resolution：up to 25fps@1920×1080	Snapshot Format：JPG Resolution：3840×2160 ,2592×1944, 1920×1080 Record Format：MP4 file Resolution：up to 25fps@1920×1080
Power consumption	DC 12V 5A	DC 12V 5A
HDMI output resolution	Auto-adaptive display up to 3840 × 2160P30	Auto-adaptive display up to 3840 × 2160P30
Supporting protocol	5G WiFi IEEE 802.11ac	5G WiFi IEEE 802.11ac
Working frequency range	5.180-5.825GHz	5.180-5.825GHz

Diagrams(Unit:mm)

① Captured by TC1200(N) with Nikon Ei

② Captured by TC800(N) with Nikon Ei

*Caputred by 8.0MP camera +Nikon Ei
